Product info

Natural Zeolite

Advantages of Zeolite

The name of zeolite comes from a Greek word that means "a stone that is boiling." So, the ore is also called "boiling stone." Zeolite includes water molecules (H2O) in the form of crystallization water as a major element in the structure; that is, zeolite is the hydrous silicate ore with aluminum. If heated extremely, zeolite melts with bubbling moisture, which looks like a stone boiling. Thus, the name is so given.
The crystallization water of zeolite is in the form of water molecules existing in the framework structure of zeolite. So, this is particularly called "zeolitic water." Even when dehydrated by heating or the like, the structure of zeolite is not destroyed. The space areas, where crystallization water used to be, remain as they are in the form of a cavity. This looks like the structure of a piece of sponge. Zeolite, according to its characteristics, strongly absorbs gas and moisture into those cavities.
Another one of the conspicuous characteristics of zeolite is its base exchange capacity. This is also called positive ion exchange capacity (cation exchange capacity: C.E.C.), which means the force that holds or releases positive ions (, potassium, sodium, calcium, etc.) as if a magnet is working. In particular, the base exchange capacity of zeolite is called permanent charge. This is not under the influence of the environment (PH or the like) in the vicinity. The force is maintained for a long period according to the characteristics.
Zeolite is classified into many types depending its structure. When it comes to natural zeolite materials, they can be classified into two major types: mordenite zeolite and clinoptilolite zeolite. These two scarcely exist alone. They usually exist with other ores. When you find something called zeolite on market, you should be careful because its purity may be often low.
In recent years, the global environmental pollution is of our great concern. Zeolite is particularly attracting our attention because of its purification capability. One of the representative examples was the "Soil Fertility Enhancement Act," which was enforced in 1984. This law was formulated from scratch at that time in order to revive the soil that was cold and devastated by chemical fertilizers into the soil that was as rich and bountiful as it used to be. According to the law, zeolite was designated as a material for the improvement of the soil. In addition to this, zeolite is a material that is effective and efficient as a type of ore for the purification of the soil, water, and air in the 21st century. This ore will be attracting more attention in the coming days.
Photos of natural zeolite with a scanning electron microscope(×5000)

Quality and Ingredients of Nitto Zeolite

Mine Cation Exchange Capacity (C.E.C) PH Crystal Structure
Iizaka Mine 160 to 190 meq/100g 6.4 Mordenite
Shiroishi Mine 160 to 170 meq/100g 6.8 Mordenite

Note;
The theoretical value of the base exchange capacity is 223meq with mordenite of 100% purity. When the measurement of Nitto zeolite is converted accordingly, the purity is as high as 71% to 85%.

Mine SiO2 Al2O3 Fe2O3 MgO CaO P2O5 Na2O K2O
Iizaka Mine 68.9 12.4 1.4 0.2 2.6 0.1 1.6 2.2
Shiroishi Mine 70.4 12.5 1.5 0.4 1.8 0.1 2.4 2.0

Product List

Type Product Net Size in mm
(Representative Value)
Mesh
For water purification ZO KAI 30-80 20kg 80 to 30 mm
ZO KAI 15-30 20kg 30 to 15 mm
Type Product Net Size in mm
(Representative Value)
Mesh
General-purpose product NITTO ZEOLITE No. 8 20kg 15.1 to 6.3 mm 1.5 to 3.2 mesh
NITTO ZEOLITE No. 6 20kg 8.0 to 5.0 mm 2.5 to 3.2 mesh
NITTO ZEOLITE No. 5 20kg 6.3 to 3.3 mm 3.2 to 6 mesh
NITTO ZEOLITE No. 3 20kg 3.3 to 1.9 mm 6 to 10 mesh
NITTO ZEOLITE No. 2 20kg 1.9 to 0.8 mm 10 to 20 mesh
NITTO ZEOLITE No. 1 20kg -0.8 mm -20 mesh
NITTO ZEOLITE #70 20kg -0.2 mm -70 mesh
NITTO ZEOLITE #150 20kg -0.1 mm -150 mesh

Type Product Net Size in mm
(Representative Value)
Mesh
Special thermal treatment ZO MG No. 3 20kg 3.3 to 1.9 mm 6 to 10 mesh
ZO MG No. 2 20kg 1.9 to 0.8 mm 10 to 20 mesh
ACT ZO No. 5 20kg 6.3 to 3.3 mm 3.2 to 6 mesh
ACT ZO No. 3 20kg 3.3 to 1.9 mm 6 to 10 mesh
ACT ZO No. 2 20kg 1.9 to 0.8 mm 10 to 20 mesh
ACT SP No. 3 20kg 3.3 to 1.9 mm 6 to 10 mesh
ACT SP No. 2 20kg -1.9 to 1.4 mm 10 to 12 mesh
Type Product Net Size
For industrial use SP #2300 20kg Representative particle diameter: 1.25 μm
SP #600 20kg Representative particle diameter: 1.92 μm

Type Product Net Size in mm
(Representative Value)
Mesh
Soil improvement (for unblended use) KEIZEON 20kg -3.3 mm -6 mesh
TAIGEN In bulk -3.3 mm -6 mesh
HI-ZEON 20kg -3.3 mm -6 mesh
PL HI-ZEON 20kg 1.0-6.0mm Granular
NITTO ZEOLITE TOKYU 20kg -3.3 mm -6 mesh
PL NITTO ZEOLITE TOKYU 20kg 1.0 to 6.0 mm Granular
IZAKA TSUCHI In bulk -10 mm

Type Product Net Blend
Compound granule soil improvement HODO SUN GREEN 5kg Blended with photosynthetic bacteria + fibrinolysis bacteria
HODO SUN ZEON 20kg Blended with photosynthetic bacteria + fibrinolysis bacteria
HODO SUN ROOT 20kg Blended with actinomyces
HODO SUN HUMIN 15kg (Granular) blended with humus
KYORYOKU ZEO HUMIN 15kg (Granular) blended with humus + charcoal + amino acid
ZEO COAL 15kg (Granular) blended with charcoal + wood vinegar + amino acid

Type Product Net Size in mm (Representative Value) Mesh
Mixed feed RYUJYO CALZEON 20kg (Granular) ZEOLITE + Calcium carbonate
MINE ZEON No. 3 20kg -0.2 mm -70 mesh
MINE ZEON No. 7 20kg -0.8 mm -20 mesh
MINE ZEON No. 20 20kg -1.9 mm -10 mesh
MINE ZEON No. 40 20kg -3.3 mm -6 mesh
MINE ZEON 610 20kg 3.3 to 1.9 mm 6 to 10 mesh
MINE ZEON 1020 20kg 1.9 to 0.8 mm 10 to 20 mesh

Type Product Net Blend
Others KEIRYO NITTO SAND Various types (Granular) for cat litter: special lightweight
KYORYOKU HOUSE DRY 15kg (Granular) for construction: blended with charcoal
HOUSE DRY 20kg For construction: (L) No. 8, (M) No. 5
Decontamination
Materials
NITTO ZEORITE KIBOU 20kg
800kg
-4mm more90% Dried product
(Shape unquestioned)
NITTO ZEORITE HIKARI 20kg
1000kg
-4mm more90% Not Dried product
NITTO ZEORITE MIZUHO 1000kg -15mm more90% Not Dried product

The sizes of these products vary depending on the factories that manufacture them. Other products of ours are manufactured after we take your orders. Just contact us for more details. We manufacture other products than the ZEOLITE products listed above on a consignment basis to meet the size and blend of your choice.
